Product Details
Place of Origin: China
Brand Name: Wangyuan
Certification: SGS
Model Number: PE pipe extrusion line equipment
Payment & Shipping Terms
Minimum Order Quantity: 1 set
Price: 79999-178888usd
Packaging Details: film
Delivery Time: 100 days
Payment Terms: TT , L/C
Supply Ability: 2 sets
Name: |
Electric Conduit Pipe Machine |
Warranty: |
1 Year |
Application: |
Plastic Extrusion Machine Hdpe Pipe Extruder PE Tube Making Machine |
Extruder Model: |
SJ120/33 With132kw AC Motor |
Extruder: |
High Speed Single Screw Extruder |
Mould: |
Plastic Drainage HDPE Solid Wall Pipe Mould |
Pipe: |
Three Layers Or Five Layers Pipe Extruding Machine |
Pipe Output: |
600-800kg.h |
Name: |
Electric Conduit Pipe Machine |
Warranty: |
1 Year |
Application: |
Plastic Extrusion Machine Hdpe Pipe Extruder PE Tube Making Machine |
Extruder Model: |
SJ120/33 With132kw AC Motor |
Extruder: |
High Speed Single Screw Extruder |
Mould: |
Plastic Drainage HDPE Solid Wall Pipe Mould |
Pipe: |
Three Layers Or Five Layers Pipe Extruding Machine |
Pipe Output: |
600-800kg.h |
Electric Conduit Wire Gas HDPE Pipe Extrusion Line Single Screw Extruder
HDPE Multi-Layer Co-Extrusion Water Supply Pipe Three/Two Layers Drainage HDPE Pipe Extrusion Line
Process flow of HDPE Plastic Water Gas Oil Supply Hose Pipe Tube Extrusion Production Line Making Machine:
Raw material+ Master Batches → Mixing → Vacuum Feeder →Plastic Hopper Drier→ Single Screw Extruder →Co-extruder for color string & Multi Layers → Mould → Vacuum Calibration Tank → Spray Cooling Water Tank → Haul-off → No Dust Cutter →Stacker → Final Product Inspecting &Packing
| Pipe ranger(mm) | 20-63 | 50-160 | 150-250 | 250-315 | 280-630 |
| Extruder | SJ60/38 | SJ75/33 | SJ90/33 | SJ120/33 | SJ150/33 |
| Capacity(kg/h) | 120-180 | 100-150 | 180-300 | 500-600 | 600-900 |
| Total power(kw) | 55 | 100 | 130 | 250 | 350 |
| Line length | 35 | 38 | 42 | 44 | 56 |
| Control system | Siemens PLC | Siemens PLC | Siemens PLC | Siemens PLCSiemens PLC |
Description of Plastic PE PPR Water Supply Drainage Electric Conduit Wire Gas Pipe Extruder HDPE Pipe Production Line
SJ-75×33 High speed single screw extruder
With SIEMENS/xima motor, Guomao/jiangchi gearbox, and Zhoushan high quality screw/barrel, which ensures good plastify capacity.
With vaccum feeding equipment.
HDPE Pipe Mold
Own designed Spiral feeding system,ensure the melting liquid pressure, even flow, no jamming. Finished pipes smooth, high density, no flow stains.
