Product Details
Place of Origin: China
Brand Name: wangyuan
Certification: SGS
Model Number: Sj80/33 + Sj50/33 extruder
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: 56888-69666usd
Packaging Details: Plastic Pipe Extruder HDPE Corrugated Pipe Making Machine Extrusion Line
Delivery Time: 50days
Payment Terms: L/C T/T
Supply Ability: 5 set per month
Pipe Name: |
HDPE Double Wall Corrugated Pipe Production Line DWC Pipe Machine Corrugated Pipe Machine |
Pipe Mould: |
38.46. 50.60. 90 Pairs |
Pipe OD: |
40.50.75.90.11.160mm |
Pipe Application: |
Double Wall Corrugated Pipe Machine |
Application: |
Drainage Pipe PVC Corrugated Pipe Extrusion Line |
Application 2: |
Both Outer Layer And Inner Layer Are Extruded Inside Die Head. |
Pipe Name: |
HDPE Double Wall Corrugated Pipe Production Line DWC Pipe Machine Corrugated Pipe Machine |
Pipe Mould: |
38.46. 50.60. 90 Pairs |
Pipe OD: |
40.50.75.90.11.160mm |
Pipe Application: |
Double Wall Corrugated Pipe Machine |
Application: |
Drainage Pipe PVC Corrugated Pipe Extrusion Line |
Application 2: |
Both Outer Layer And Inner Layer Are Extruded Inside Die Head. |
The characteristics of fully automatic plastic double wall corrugated drain pipe extrusion making machine:
1. The fully automatic plastic double wall corrugated drain pipe extrusion making machine uses two high-speed single-screw extruders. Single-screw extruder:
We use PE high-speed high-efficiency single-screw extruder. Its barrel is slotted type design.
It is also equipped with a low-noise fan and a high-speed hard-surface gear box.
The inner and outer layers of the double wall corrugated pipes are independently fed by two extruders.
It achieves the use of different colors and different raw materials production, and ensures efficient extrusion.
2. Extrusion mold: It has dual flow channel structure. It goes through the nitriding and polishing process.
The special design of the die is suitable for the production of different materials and different ring stiffness pipes.
The special mold structure ensures that the inner and outer layers are evenly and stably formed.
3. Forming machine: It adopts horizontal structure and chain drive design. At the same time, it is also equipped with an open water cooling system and a vacuum forming system. This ensures a high production rate for continuous production.
The mold adopts the mechanical up and down synchronous drive and the advanced programmable lubrication system.
These make the molds have a long service life, ensure the accuracy of the operation and ensure the quality of the pipe. Because of using advanced online expansion function, we can expand the double wall corrugated pipe online.
This significantly reduces the investment and the improves production efficiency.
4. Molds: The corrugated forming module is made of special alloy material through precision casting. It has high precision, strength, wear resistance and excellent heat dissipation effect. By using advanced module rapid replacement system,
the replacement time of the module is greatly reduced. According to the different requirements of different customers ,
we can design different wave type forming module.
