The common configurations of a five layer co extruded pipe oil pipeline production line include: whatsapp 008615753291269 ms lucy   1. Extruder system: Different specifications of extruders are used for extruding materials from different layers. 2. Co extrusion head: Ensure uniform fusion of materials in each layer. 3. Setting cooling device: shaping and cooling the pipe material. 4. Tractor: Pull the pipe forward at a constant speed. 5. Cutting machine: Cut pipes according to the required length. Its advantages mainly include the following points: 1. Excellent performance: The five layer structure can achieve better strength, corrosion resistance, and sealing, and can adapt to different oil transportation environments and requirements. 2. Multifunctionality: The performance of each layer of materials can be flexibly adjusted according to specific needs to meet diverse application scenarios. 3. High quality assurance: The precise co extrusion process ensures the consistency and stability of pipe quality. 4. Long lifespan: With good durability, it extends the service life of oil pipelines. 5. Efficient production: With a high degree of automation, it can achieve large-scale continuous production and improve production efficiency.  Name of Commodity   Quantity   20-110mm high speed PE pipe production line 1.SJ75/33 extruder with loader (75KW motor ，DELTA inverter ,siemens contactor ,ORMON meters)With autoloader and dryer 1 set 2.SJ30/25 extruder for marking line 1 set 3. 20-110mm high speed PE pipe mould Pipe speed can reach 25m.min on 20,25mm 1 set 9m vacuum tank 304stainless Vacuum frequency conversion control with dual filter pipelines, dual pipelines enable screen replacement without stopping the machine 1 set 9m spraying cooling water tank 1 set Tractor machine 4kw motor 1 set Non-dust Cutter machine max speed 25m.min 1 set Stacker 1 set Double position winder for 20-63MM 1 set Single position winder for 63-110mm 1 set Spare parts free Test pipe machine in our factory charge   FOB QINGDAO USD   NO Description Unit Remark ﹡ automatic water level control ﹡ electric cabinet with water-proof protection ﹡ forceful concentrated spraying water cooling with good cooling effect ﹡ vacuum pump and water pump adopts intelligent pump with self protection function ﹡ Perfect pipeline design can keep nozzle unblocked Function: calibrate the outer diameters and cooling pipe primarily 1 Length of the tank mm 9000 2 Material of water tank   stainless steel, SUS304 3 Sizing bushing material   Stannum-bronze 4 Cooling Mode   Spray-pouring cooling 5 Pouring areas   4 6 Water Pump Power KW 2.2kw×2set 7 Vacuum Pump Power KW 2.2+3kw Yulong brand 8 Vacuum Degree Mpa -0.03—0.05 9 Motion Range of Forward and backward mm ±600, motor drive 10 Up-down Adjusting Range mm ±50, by manual 11 Figure dimension mm 9000×800×1250 12 weight kg 1250

COD communication cluster tubes making machine   Video : https://youtu.be/r2k7BtYkIAs?si=HJ0LbzebUrO4Hi02   COD communication cluster tubes are a new type of micro-cable protection sleeve. They are made by extruding HDPE (high-density polyethylene) resin and have the following advantages:   1. COD communication cluster tubes  is Strong compression resistance: The inner tubes of COD tubes are tightly attached to the inner wall of the outer tube during the production process. The inner tubes are smooth, which makes the construction convenient.   2. COD communication cluster tubes  is Strong compression resistance: The inner tubes of COD tubes are tightly attached to the inner wall of the outer tube during the production process. The inner tubes are smooth, which makes the construction convenient.   3. COD communication cluster tubes  is Strict pressure testing: The inner tubes of COD tubes are pre-tested with strict pressure before being used in the production of the complete COD tubes. In addition, the special helical shape of the outer tube enhances the compression resistance of the traditional PE straight tubes. Therefore, the compression resistance of COD tubes is extremely strong. Even in the event of an earthquake or building collapse, it can ensure safety.   4. COD communication cluster tubes  is Strong acid and alkali resistance: COD tubes have extremely strong acid and alkali resistance, so they can be corrosion-resistant during the laying process in sea water or wetlands, thereby protecting the communication line.   5. Long production length: The production length of COD tubes can reach more than 1,000 meters per roll, thereby improving the laying efficiency of communication lines. The advantages and functions of the cluster tube and COD tube equipment:   COD communication cluster tubes  Advantages:   • High efficiency in production and processing.   • Stable performance and reliable quality. Functions:   • It is mainly used for the production and installation of pipeline systems, providing a stable and reliable pipeline connection.   • Can meet the requirements of different engineering applications, ensuring the smooth operation of the pipeline. whatsapp 008615753291269 ms lucy

PE sprial pipe corrugated machine Pipe/Tube Extrusion Line/Soft Pipe Flexible Pipe Machine   Electricity Conduit Tube machine and electricity pipe machine https://www.cuishiextruder.com/plastic-cable-protection-spiral-pipe-machine-hdpe-spiral-pipe-production-line-machinery-product/   Qingdao cuishi plastic machinery started to make the Electricity Conduit Tube machine and PE sprial pipe machine since 1999 and mainly to make the sprial corrugated pipe machine    The following is the whole line including the single screw extruder for pp pe and die head and calibration table and hauling off and cutter and pipe winder machine   Install a cutting machine between the tractor and the forming machine to cut and produce online     price of plastic extrusion machine is about 20000-30000usd depends on the customer output need and request   Test video : https://youtube.com/shorts/sDTAqYVJIO8?feature=share   The output customer must provide: 1) thread height, pitch, corrugation shape, 2) melted fat of PE raw material, 3) cooling water temperature for normal 24-hour production     Our vacuum calibration table adopt the chiller system inside and can control the water temperate very well and cooling faster and improve the speed   whatsapp 008615753291269 ms lucy   HDPE Corrugated Conduit Specfication       ID OD Thickness Pitch Roll (m) Pilot Wire Diameter 30 40 1.4 10 300 1.9 50 65 1.4 17 200 1.9 80 102 1.9 25 100 1.9 100 130 2 32 100 1.9 125 160 2.2 39 100 1.9 150 188 2.5 47 50 1.9 200 253 3 55 50 1.9
